Sizes with section weight of equal angles:
As per British Standards thickness used to be represented by Gauge (G).
Size(mm) | Weight (kg/ft.) | Guage (Per Mtr.) |
---|---|---|
20x20x3 | 0.274 | 0.899 |
25x25x3 | 0.335 | 1.099 |
25x25x5 | 0.548 | 1.798 |
31x31x3 | 0.390 | 1.280 |
35x35x5 | 0.792 | 2.599 |
37x37x3 | 0.518 | 1.700 |
40x40x3 | 0.548 | 1.798 |
40x40x6 | 1.066 | 3.498 |
50x50x6 | 1.372 | 4.502 |
60x60x6 | 1.645 | 5.397 |
80x80x6 | 2.224 | 7.297 |
Size(mm) | Weight (Per Mtr.) |
---|---|
30x20x3 | 1.1 |
30x20x5 | 1.8 |
40x25x3 | 1.5 |
40x25x6 | 2.8 |
45x30x3 | 1.7 |
45x30x6 | 3.3 |
50x30x3 | 1.8 |
50x30x6 | 3.5 |
60x40x5 | 3.7 |
60x40x8 | 5.8 |
65x45x5 | 4.1 |
